ورودی ویدئو |
Audio Input:, 16-ch
Video Compression:, H.265+/H.265/H.264+/H.264
Analog and HD-TVI video input:, 16-ch,BNC interface (1.0Vp-p, 75 Ω)connection
Supported camera types:, Support HDTVI input: 5MP,4MP,3MP,1080P/25Hz, 1080P/30Hz,720P/25Hz, 720P/30Hz, 720P/50Hz, 720P/60Hz,
Support AHD input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz
Support CVI input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz
Support CVBS input
Video Input Interface:, BNC (1.0 Vp-p, 75Ω)
Audio Compression:, G.711u
Audio Input Interface:, 4-ch, RCA (2.0 Vp-p, 1 KΩ)
Two-way Audio:, 1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input)
|
خروجی ویدئو |
CVBS Output:, 1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704×576,NTSC:704×480
HDMI/VGA Output:, VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Recording resolution:, 5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
Frame Rate:, Main stream:
5 MP@12fps/4 MP@15fps/3 MP@18fps
1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF/CIF@25fps (P)/30fps (N)
Video Bit Rate:, 32 Kbps-10 Mbps
Stream Type:, Video/Video&Audio
Two-way Audio:, 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Audio Output:, 1-ch RCA(Linear, 1kΩ)
Audio Bit Rate:, 64kbps
Dual Stream:, Support
Playback Resolution:, 5MP/4MP/3MP/1080p/720p/VGA/WD1/4CIF/CIF/QVGA/QCIF
Synchronous Playback:, 16-ch
|
network |
Remote connections:, 128
Network protocols:, TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
|
